Automatic Glass Double Edger Processing Line
📊Basic Specifications
Processing Thickness3-19 mm
Voltage380V
Warranty1 Year
StatusHorizontal
Max. Glass Size2500X2500mm
Min. Glass Size25X25mm
Transmission Speed0.5-6m/Min
Bevel Angle0-45°
Max. Hypotenuse Width50mm
Production Capacity500 sets/Year
📝Product Introduction
A series of glass double edging machines designed for flat and pencil finishes. These machines process glass horizontally, polishing opposing edges concurrently, making them ideal for high-volume production where parallel sides are essential. Configurations range from small units (40mm x 40mm) to large-scale double-edgers capable of handling up to 4.5m per dimension.
Depending on polish requirements, machines come fitted with 8 to 24 spindle motors. These units can work as standalone machines or in sequence with a turntable to polish all four sides in a single pass. Features include a Schneider 10.7" color touch interface for precise control over speed and thickness.
⚙️Key Performance Features
- Simultaneous processing of double parallel straight lines (bottom and arris) via rough, fine grinding, and pneumatic polishing.
- All-in-one structure for machine and circuit box: waterproof, space-saving, and durable cast iron main body with annealing treatment.
- High-precision linear guides and screw mandrels ensure movement accuracy and stability.
- Integrated position correction device to solve deviation issues for small glass processing.
- PLC control with a touch screen for real-time grinding status monitoring and automatic adjustments.
- Advanced pneumatic polishing with linear guide rails for stable, reliable, and wheel-saving operation.
🎡Wheel Placement & Parameters
| Parameter |
Specification |
| Glass Thickness | 3-25mm |
| Min Processed Size | 350*350mm |
| Max Processed Size | 4200mm(CGSZ4225) |
| Process Speed | 1-15m/min |
| Working Height | 920mm |
| Total Power | 47kw |
⭐Highlighted Features
• ABB Motors
• Pencil or Cup Wheels
• Custom Sizes Available
• Optical Glass Sensor
• Touch Screen Interface
• Fast Adjustment System
🔩Main Spare Parts List
| No. |
Parts Name |
Brand |
| 1 | Grinding Motor | ABB Motor |
| 2 | Transmission Shaft Motor | CDQC frequency conversion motor |
| 3 | Timing belt | Barbieri (Italy) |
| 4 | Straight line guide | Bosch Rexroth (Germany) |
| 5 | Ball Screw Shaft | ABBA (Taiwan) |
| 6 | Photoelectric switch | Panasonic (Japanese) |
| 7 | Frequency converter | TAIAN (Taiwan) |
| 8 | PLC | SIEMENS(Germany) or DELTA(Taiwan) |
| 9 | Touchscreen | SIEMENS(Germany) |
| 10 | Circuit-breaker \ Connector | Schneider (France) |
| 11 | Intermediate Relay | OMRON |
| 12 | Position encoder | Japan's Omron |
| 13 | Cooling tank | Stainless steel |
